Epiroc MG 100
Carrier Weight Class | 0,7 - 1,2 t |
Operating Weight | 90 kg |
Product Weight | 71 kg |
Jaw Opening | 600 mm |
Grab Width | 310 mm |
Oil Flow | 10 - 15 l/min |
Oil Flow Rotation | 3 - 5 l/min |
Multi grapples Epiroc MG Series
Epiroc sorting grapples for excavators are ideal for demolition, recycling, or sorting tasks. The sorting grapple is used for sorting and clearing various materials, light demolition, transferring wood, or moving construction materials.
The hydraulic sorting grapple is designed for fast and efficient operation. The slewing ring allows 360-degree rotation of the grapple; if you have a tiltrotator, a slewing ring is not required on the grapple. The Epiroc sorting grapple comes equipped with one hydraulic rotation motor up to the MG 1000 model and two hydraulic rotation motors from the MG 1000 model onwards, ensuring reliability when gripping materials. The Epiroc MG sorting grapple is available for excavators weighing between 0.7 and 100 tons.
Are you looking for a sorting grapple for excavators? Below, you’ll find our selection for easy comparison, helping you find the perfect attachment for your project! Prefer personal advice? Contact us or fill out the quote form!
Features
- Detachable rotation for correct use with tiltrotators.
- 360-degree rotation ensures optimal positioning and precise control.
- Integrated mechanical stop to reduce stress on the cylinders.
- Wear blades are both replaceable and reversible to reduce grapple wear.
Optional
- Tooth blades for block and stone handling. (MG 400 - 2300)
- Side plates for handling fine-grained material and debris. (MG 400 - 1500)
- Hatcon tracking system allows performance tracking of the attachment in real-time.
