Xcentric Ripper XR Series 0

The Xcentric Ripper Series 0 is designed for mining applications, where the highest production values are required, along with continuous shift work, making the reliability and comfort of operating the excavator essential.

The Series 0 is made from wear-resistant steel, making it virtually maintenance-free. Thanks to its uncomplicated mechanical design, it contains no expensive components, keeping maintenance costs very low. The ripper is suitable for excavators weighing between 7 and 150 tons.

Are you looking for a ripper for excavators? Below you’ll find our range and an easy comparison to help you select the right attachment for your project. Prefer personal advice? Contact us or fill out the quote form!

Features

Minimum noise level 10 dB quieter than a hammer.
Underwater usable without modifications.
HARDOX Protection a special hard, wear-resistant steel alloy that hardly wears down.

Direct & Personal

Sales Netherlands

Request a quote

Fotogalerij

XR10

Datasheet XR10
Hydraulic Excavator	7 - 10 ton
Ripper Weight (incl. Top Plate)	930 kg
Ripper Weight (without Top Plate)	829 kg
Hydraulic Working Pressure	15 - 18 MPa
Hydraulic Return Pressure	0.6 MPa
Hydraulic Oil Flow min.	L/Min
Max. Drain Line Pressure	0.4 MPa
Frequency	1500 1/min
Dimensions L x W x H	168 x 45 x 90 cm
Dimension A	102 cm
Dimension B	76 cm
Accumulator Pressure	0.6 MPa

Request a quote

XR15

Datasheet XR15
Hydraulic Excavator	11 - 16 ton
Ripper Weight (incl. Top Plate)	1700 kg
Ripper Weight (without Top Plate)	1550 kg
Hydraulic Working Pressure	16 - 19 MPa
Hydraulic Return Pressure	0.6 MPa
Hydraulic Oil Flow min.	120 L/min
Max. Drain Line Pressure	0.4 MPa
Frequency	1400 1/min
Dimensions L x W x H	220 x 66 x 130 cm
Dimension A	140 cm
Dimension B	105 cm
Accumulator Pressure	0.5 MPa

Request a quote

XR20

Datasheet XR20
Hydraulic Excavator	18 - 24 ton
Ripper Weight (incl. Top Plate)	2500 kg
Ripper Weight (without Top Plate)	2200 kg
Hydraulic Working Pressure	18 - 20 MPa
Hydraulic Return Pressure	0.6 MPa
Hydraulic Oil Flow min.	160 L/min
Max. Drain Line Pressure	0.4 MPa
Frequency	1400 1/min
Dimensions L x W x H	240 x 78 x 175 cm
Dimension A	165 cm
Dimension B	130 cm
Accumulator Pressure	0.5 MPa

Request a quote

XR30

Datasheet XR30
Hydraulic Excavator	24 - 30 ton
Ripper Weight (incl. Top Plate)	3300 kg
Ripper Weight (without Top Plate)	2800 kg
Hydraulic Working Pressure	22 - 24 MPa
Hydraulic Return Pressure	0.6 MPa
Hydraulic Oil Flow min.	180 L/min
Max. Drain Line Pressure	0.4 MPa
Frequency	1300 1/min
Dimensions L x W x H	280 x 85 x 160 cm
Dimension A	179.1 cm
Dimension B	139.1 cm
Accumulator Pressure	0.5 MPa

Request a quote

XR40

Datasheet XR40
Hydraulic Excavator	32 - 40 ton
Ripper Weight (incl. Top Plate)	4200 kg
Ripper Weight (without Top Plate)	3600 kg
Hydraulic Working Pressure	22 - 24 MPa
Hydraulic Return Pressure	0.6 MPa
Hydraulic Oil Flow min.	200 L/min
Max. Drain Line Pressure	0.4 MPa
Frequency	1200 1/min
Dimensions L x W x H	310 x 90 x 184 cm
Dimension A	200 cm
Dimension B	155 cm
Accumulator Pressure	0.5 MPa

Request a quote

XR50

Datasheet XR50
Hydraulic Excavator	42 - 55 ton
Ripper Weight (incl. Top Plate)	5600 kg
Ripper Weight (without Top Plate)	5000 kg
Hydraulic Working Pressure	26 - 28 MPa
Hydraulic Return Pressure	0.6 MPa
Hydraulic Oil Flow min.	250 L/min
Max. Drain Line Pressure	0.4 MPa
Frequency	1000 1/min
Dimensions L x W x H	320 x 90 x 190 cm
Dimension A	210 cm
Dimension B	165 cm
Accumulator Pressure	0.4 MPa

Request a quote

XR60

Datasheet XR60
Hydraulic Excavator	55 - 70 ton
Ripper Weight (incl. Top Plate)	7000 kg
Ripper Weight (without Top Plate)	5700 kg
Hydraulic Working Pressure	26 - 28 MPa
Hydraulic Return Pressure	0.6 MPa
Hydraulic Oil Flow min.	280 L/min
Max. Drain Line Pressure	0.4 MPa
Frequency	1000 1/min
Dimensions L x W x H	345 x 110 x 217 cm
Dimension A	226 cm
Dimension B	176 cm
Accumulator Pressure	0.25 MPa

Request a quote

XR80

Datasheet XR80
Hydraulic Excavator	70 - 100 ton
Ripper Weight (incl. Top Plate)	10.500 kg
Ripper Weight (without Top Plate)	8700 kg
Hydraulic Working Pressure	30 - 32 MPa
Hydraulic Return Pressure	0.6 MPa
Hydraulic Oil Flow min.	300 L/min
Max. Drain Line Pressure	0.4 MPa
Frequency	850 1/min
Dimensions L x W x H	470 x 120 x 250 cm
Dimension A	300 cm
Dimension B	225 cm
Accumulator Pressure	0.5 MPa

Request a quote

XR120

Datasheet XR120
Hydraulic Excavator	100 - 150 ton
Ripper Weight (incl. Top Plate)	13.000 kg
Ripper Weight (without Top Plate)	11.00 kg
Hydraulic Working Pressure	22 - 24 MPa
Hydraulic Return Pressure	0.6 MPa
Hydraulic Oil Flow min.	600 L/min
Max. Drain Line Pressure	0.4 MPa
Frequency	1000 1/min
Dimensions L x W x H	400 x 132 x 282 cm
Dimension A	243 cm
Dimension B	180 cm
Accumulator Pressure	0.6 MPa
